MHPC8
MISTER HITCHES Pintle Hook Combo - 8 TONNE Low Wear

MISTER HITCHES Pintle Hook Combo - 8 TONNE Low Wear

  • Sale
Tax included.
  • POWDER COATED FINISH
  • FITS TO PINTLE RECEIVER ARM (MHPRA) OPTIONAL
  • INCLUDES LOCKING SAFETY CATCH & MOUNTING HARDWARE (4 x GRADE 8 BOLTS & NUTS)
  • USED IN AGRICULTURE, MINING, 4X4 AND WHERE SHIFTING HEAVY LOADS IS REQUIRED - EG. PLANT TRAILERS
  • CAN BE USED WITH STANDARD 50MM BALL COUPLINGS OR WITH 75mm PINTLE RING COUPLING
  • TOW BALL CAPACITY = 3500kg
  • PINTLE HOOK CAPACITY = 8000kg
  • MAX. T.W. TONGUE WEIGHT 1360kg
  • FULLY FORGED (NOT CAST) LOW WEAR DESIGN
  • MOUNTING POSTITIONS = 85MM x 45MM x 13.5MM
  • INSTRUCTIONS AND H.T. HIGH TENSILE MOUNTING HARDWARE INCLUDED
  • 2 MILLION CYCLE DYNAMICALLY TESTED IN AUSTRALIA TO ADR62/02
  • D-VALUE 36kN
